ALL-CARB 3 HP 3450 RPM Electric Motor – Compressor Duty, 56 Frame, 115/230V, Single Phase

This ALL-CARB 3 HP electric motor is built for compressor duty.

It runs at 3450 RPM on 115V or 230V (single phase).

It's a 56 frame motor with an ODP (open drip-proof) enclosure.

The shaft is 5/8 inches, keyed, and about 1.88 inches long.

It draws 18.0 amps at 115V and 9.0 amps at 230V.

Rotation is counter-clockwise when viewed from the shaft end.

It's a non-reversible motor with a service factor of 1.0.

Weighs about 42 pounds.

Perfect for powering air compressors or other equipment needing a 3HP, 3450 RPM motor.

Model DP120356SL.

It's a solid, heavy-duty unit ready to work.
