11x17 COLOR Wiring Diagram - Jaguar XKE 4.2L Series I 1964-1968 | Prospero's Garage

Restoring a classic Jaguar XKE?

Don't get lost in a mess of wires.

This is a brand new, large format 11x17 COLOR wiring diagram specifically for the Jaguar XKE 4.2L Series I, covering model years 1964 through 1968.

It's printed on paper and published by Prospero's Garage.

Having this in color makes tracing circuits way easier than squinting at a black and white manual.

It's a service/repair manual type of literature, but just the essential wiring schematic.

Made in the USA.

Whether you're chasing an electrical gremlin or doing a full rewire, this diagram is a must-have.

Get your XKE's electrics sorted with this clear, detailed guide.
