5HP General Purpose Electric Motor – 3450RPM, 208-230V, Single Phase, 5/8" Shaft, TEFC

Need a workhorse motor?

This 5HP general purpose electric motor from Villdomall delivers.

It's a single phase, 208-230V, 3450 RPM, with a 5/8-inch shaft.

Totally enclosed fan cooled (TEFC), IP55 rated, insulation class F.

Mounts on a base, reversible, induction/asynchronous type.

Frame size 56C, 2 pole, 60 Hz.

Current draw is around 22A (208V) to 21A (230V).

Rolled steel shell, weighs about 52 lbs.

Protector included.

Great for compressors, pumps, conveyors, or shop tools.

MPN 161317-vil.

Brand new, ready to wire up.

If you've got a machine that needs a new heart, this motor will get it spinning.

No UPC.
