DIY Large Diaphragm Condenser Microphone Circuit Board – Dl45 Style

Hey audio DIYers!

Here's your next project.

This is a circuit board for a large diaphragm condenser microphone, inspired by the classic dl45 style.

It's a brand new, unbranded board made in China, ready for you to populate with components and build your own high-quality studio mic.

It uses a condenser transducer type and is designed for a large diaphragm capsule.

The board is black and has all the traces laid out.

If you're into building your own gear and want a custom microphone, this is a great place to start.

You'll need to source your own capsule, body, and components, but the hardest part (the board) is already done.

Time to get soldering!
